Product Highlights:
GPU Architecture: NVIDIA Blackwell with DLSS 4
CUDA Cores: 4,608
Video Memory: 16 GB GDDR7 @ 28 Gbps, 128‑bit bus
Boost Clock: 2,572 MHz (OC mode)
PCIe Interface: PCI‑E 5.0 x8
Display Outputs: 3× DisplayPort 2.1b (UHBR20), 1× HDMI 2.1b
Power Connector: 1× 8‑pin (180 W TDP; requires 600 W PSU)
Cooling & Design:
IceStorm 2.0 Dual‑Fan Cooling with BladeLink fan blades & FREEZE Fan Stop
Compact 2‑slot form factor, SFF‑ready
Metal backplate for rigidity and heat dissipation
FireStorm Utility for custom fan curves and RGB control
Dimensions & Fitment:
Card Size: 220.5 × 120.25 × 41.6 mm (8.7″ × 4.7″ × 1.6″)
Slot Width: 2 slots
Key Features & Benefits:
Next‑gen DLSS 4 acceleration for buttery‑smooth 1440p/4K gaming
Low‑noise fans that stop completely at idle
Compact build fits most mid‑tower and SFF cases
Robust power delivery for stable overclocking
What’s Included:
ZOTAC GAMING RTX 5060 Ti Twin Edge GPU
User manual
Quick‑start guide
Specifications
| GPU | NVIDIA GeForce RTX 5060 GPU |
| CUDA Cores | 3840 |
| Video Memory | 8 GB GDDR7 |
| Memory Bus | 128-bit |
| Engine Clock | 2550 MHz |
| Memory Clock | 28 Gbps |
| PCI Express | PCI Express 5.0 x8 |
| Display Outputs | 3 x DisplayPort 2.1b with UHBR20 1 x HDMI® (2.1b, supports VRR & DSC) |
| Display Capabilities | - Up to 4K 480Hz or 8K 165Hz (DisplayPort, with DSC) - Up to 4K 480Hz HDR or 8K 120Hz HDR (HDMI, with DSC) |
| HDCP Support | 2.3 |
| Multi-Display Capability | Quad Display |
| Recommended Power Supply | 600W |
| Power Consumption | 155W |
| Power Input | 1 x 8-pin power connector |
| DirectX Support | Microsoft DirectX® 12 Ultimate |
| OpenGL Support | 4.6 |
| Cooling | Air Cooled |
| Slot Size | 2 |
| SLI Support | No |
| Supported OS | Windows 11 / Windows 10 64-bit (v1809 or later) |
| Card Dimensions | 220.5 mm x 120.25 mm x 41.6 mm (8.7" x 4.7" x 1.6") |
| Accessories | User Manual |
